UNS N06600/Inconel 600/NS312/2.4816 Inconel Alloy Bar / Rod / Wire / Forging / Plate / Strip With Excellent Mechanical Strength For Furnace Components
UNS N06600 (Inconel 600 / NS312 / 2.4816) is a nickel-chromium-iron alloy known for its excellent oxidation and corrosion resistance, particularly in high-temperature and moderately corrosive environments. It retains mechanical strength across a wide temperature range and resists chloride-ion stress corrosion cracking. In bar, rod, wire, forging, plate, and strip forms, it's widely used in chemical processing, heat treatment, nuclear reactors, and aerospace. The alloy offers good weldability, fabricability, and thermal stability. Common applications include furnace components, heat exchanger tubes, steam generators, and pressure vessels. Its versatility and durability make it a top choice for demanding thermal and chemical environments.
Trade Code
| Chemical Composition Wt.% | % | Ni | Cr | Fe | C | Mn | Si | Cu | S |
| Min | 72 | 14 | 6 | | | | | |
| Max | | 17 | 10 | 0.15 | 1 | 0.5 | 0.5 | 0.015 |
| Physical Constants | Density(g/cm³) | 8.47 |
| Melting Range(℃) | 1370-1425 |
| Minimum mechanical properties of alloy at room temperature | Typical mechanical properties | Tensile strength Rm N/mm² | Yield strength RP 0.2 N/mm² | Elongation A5 % | Brinell Hardness HB |
| Annealing treatment | 550 | 240 | 30 | 195 |
| Solution treatment | 500 | 180 | 35 | 185 |
Overview of Inconel 600
Inconel 600 is a nickel-chromium-iron alloy designed for excellent performance in high-temperature and corrosive environments. It's highly versatile due to its oxidation resistance, thermal strength, and good fabricability.
Key Features (All Forms)
Outstanding High-Temperature Performance
- Retains strength and structural integrity at elevated temperatures up to 1090°C (2000°F).
- Great for thermal cycling and oxidation environments (e.g., furnaces, heaters).
Excellent Corrosion Resistance
- Resists a wide range of corrosive media, including:
Organic acids
Alkaline solutions (e.g., caustic soda)
Chloride ion stress corrosion cracking
- Performs well in both oxidizing and reducing environments.
Good Mechanical Properties
- High strength and toughness across a broad temperature range.
- Non-magnetic, with good fatigue and creep resistance.
Good Fabricability and Weldability
- Easily formed, machined, and welded using conventional methods.
- Resistant to post-weld grain boundary corrosion.
Form-Specific Applications
Bar / Rod
- Used for shafts, fasteners, fittings, valve stems, and bolting in high-temp and corrosive environments.
- Excellent machinability and dimensional stability.
Wire
- Applications include heating elements, springs, mesh, and welding wire.
- Performs well in electrical resistance applications and thermal cycling.
Forging
- Used to create custom flanges, valve components, high-stress fittings, and rotor parts.
- Suitable for nuclear and aerospace parts requiring robust performance.
Plate / Strip
- Ideal for furnace components, chemical processing equipment, heat exchangers, and ductwork.
- Uniform corrosion resistance and thermal durability.
